限られる高度の器械Co.
質およびサービスで進められるため!
| 起源の場所: | 中国 |
|---|---|
| ブランド名: | Advanced Instruments |
| 証明: | UL 94;IEC 60695-11-10 |
| モデル番号: | AIC-52031 |
| 最小注文数量: | 1セット |
| 価格: | $3000~$5000 |
| パッケージの詳細: | 合板ケース |
| 受渡し時間: | 30日間 |
| 支払条件: | L/C、T/T、D/P |
| 供給の能力: | 30セット/月 |
| アフターサービス: | 12 時間 12 か月以内に対応 | 保証: | 丸1年 |
|---|---|---|---|
| 輸送パッケージ: | 合板ケース | 試験規格: | UL 94;IEC 60695-11-10 |
| ガス: | 空気とプロパン | テストオブジェクト: | プラスチック材料 |
| 手術: | 自動 | 電源: | AC220V、50/60Hz、1A |
| ガス源: | メタン、空気 | 仕様: | 1050mm×750mm×1400mm(外形寸法) |
| 制御システム: | タッチスクリーン付きPLC | バーナーの位置決め: | 空気圧 |
| 炎の高さ: | 18~22mm | 角度変換: | プッシュプル装置 90°、20°、45° |
| ハイライト: | UL 94,IEC60695-11-10,Horizontal Vertical Flame Tester |
||
Horizontal and vertical burning tester is mainly used to determine the non-combustible properties of plastics or films under the direct combustion of the specified ignition source, to judge the refractory grade of refractory materials. UL 94 is one of the most important UL standards for fire safety test methods. He is particularly important for plastics used in the electrical industry, and the test method is based on UL's research on the flame retardant properties of plastics, which is not only applicable to the electrical industry, but also to many other fields, suitable for lighting equipment,low-voltage electrical appliances, household appliances, motors, tools, instruments and other equipment, as well as electrical and electronic products and their component parts such as electrical connections and other research, production and quality inspection departments, but also for insulation materials, Engineering plastics or other solid combustible materials industry.
1.2 Related standards
1.Controller: 7" colour touch screen and PLC control
2.Burner positioning: Pneumatic
3.lgnition time:0 ~99.99s arbitrarily settable, the residual flame time andafterglow time are automatically recorded
4.Flame height: 18~22mm
5.Angle conversion: push-pull device 90°,20°.45°
6.Burner: lmported from USA HUMBOLDT applying with the requirements of ASTM D 5025-99
7.Flowmeter:0~500mL/min
8.Burner inner diameter: 9.5mm.
•Overall Demensions:1050mm(W)x750mm(D)x1400mm(H)
•Power Supply:AC220V 50/60HZ 1A
•Gas source: Methane,air(provided by the customer)
