| 起源の場所: | 中国 |
|---|---|
| ブランド名: | Advanced Instruments |
| 証明: | ASTM D93;ISO 2719 |
| モデル番号: | PMCC-A |
| 最小注文数量: | 1セット |
| 価格: | US$1500-2500/set |
| パッケージの詳細: | 合板ケース |
| 受渡し時間: | 15日間 |
| 支払条件: | T/T、L/C、D/P |
| 供給の能力: | 月額100セット |
| 正確さ: | ±0.1℃ | 供給電圧: | AC ((220±10%) V 50Hz |
|---|---|---|---|
| 画面: | 液晶 | 加熱モード: | 手動で調整する |
| イグニッションモード: | 点火ガン | テスト標準: | ASTM D93;ISO 2719 |
| ハイライト: | ASTM D93 Flash Point Tester Manufacturer,Closed Cup Flash Point Testing Machine,Flash Point Analyzer |
||
|
Power supply
|
AC(220±10%)V, 50Hz
|
|
Heating device
|
(1)The furnace is silicon carbide material. Power is 600W heating wire.
(2) The heating power is adjustable from 0 W to 600W. |
|
Rate of sample’s heating up
|
Procedure A :(5~6 )℃/min;
Procedure B:(1~1.5)℃/min; Procedure C: (2.5~3.5)℃/min |
|
Electric stirring device
|
(1)Stirring motor:(BYGH101stepping motor)
(2) Driving mode:flexible axle (3) Stirring vane size:8mm×40mm |
|
Stirring rate
|
Accord with the requirements of GB/T 261.
(1) 90~120 turns/min, suitable to test procedure A. (2)(250±10)turns/min, suitable to test procedure B. (3)90~120 turns/min, suitable to test procedure C |
|
Standard oil cup
|
Accord with the requirements of GB/T 261.
(1) Inner diameter;50.7mm~50.8mm (2) Depth;55.7mm~56.0mm (3) Scribed line depth of capacity of oil sample:33.9mm~34.3mm (4) Capacity of oil sample:about 70ml |
|
Igniting device
|
Igniting source:gas(or other civilian fuels, the same below)
|
|
Temperature testing probe
|
Pt100
|
|
Ambient temperature
|
15°C~35°C,
|
|
Relative humidity
|
≤ 85%
|
|
Power consumption
|
≤ 650W
|
| Dimension | 340mm×330mm×380mm |
| Net weight | 9kg |
|
Item
|
Name
|
Unit
|
Qty
|
Remarks
|
|
1
|
Main unit
|
Set
|
1
|
Including ignition unit, oil cup etc.
|
|
2
|
Temperature sensor
|
Piece
|
1
|
Has been installed in the instrument
|
|
3
|
Oil cup
|
Piece
|
1
|
|
|
4
|
Driving flexible shaft
|
Piece
|
1
|
|
|
5
|
latex tube φ3 250mm
|
Piece
|
3
|
|
Package Photos
